A lightweight, streamlined clamp generally used in small diameter applications such as air & fuel lines. The streamlined configuration allows for installation in tight fitting or difficult to reach areas. This clamp creates high sealing pressure with only 10 to 15 in./lbs. of installation torque.
|
5/16" (7.9 mm) band
1/4" (6.4 mm) slotted hex head screw
Per SAE standard J1508 Type ”M”
| 4 |
7//32 |
5.6 |
5/8 |
16 |
3504 |
3604 |
3704 |
3804 |
| 6 |
7/16 |
11 |
25/32 |
20 |
3506 |
3606 |
3706 |
3806 |
| 8 |
1/2 |
13 |
29/32 |
23 |
3508 |
3608 |
3708 |
3808 |
| 10 |
9/16 |
14 |
1-1/16 |
27 |
3510 |
3610 |
3710 |
3810 |
| 12 |
11/16 |
17 |
1-1/4 |
32 |
3512 |
3612 |
3712 |
|
| 16 |
15/16 |
24 |
1-1/2 |
38 |
3516 |
3616 |
3716 |
|
| 20 |
1-3/16 |
30 |
1-3/4 |
44 |
3520 |
3620 |
3720 |
|
| 24 |
1-7/16 |
37 |
2 |
51 |
3524 |
3624 |
3724 |
|
| 28 |
1-11/16 |
43 |
2-1/4 |
57 |
3528 |
3628 |
3728 |
|
| 32 |
1-15/16 |
49 |
2-1/2 |
64 |
3532 |
3632 |
3732 |
|
